- H.265/H.264 codec coding
- Max 80Mbps incoming bandwidth
- up to 1ch@8MP/4ch@1080P decoding
- HDMI/VGA simultaneous video output
- Support IPC UPnP, 4PoE ports
- PoE
| Resolution | 8MP/6MP/5MP/4MP/3MP/1080P/720P/D1 | |
| Video Compression | H.265/H.264 | |
| Camera Input | 4 Channel | |
| Record Frame Rate | 80Mbs | |
| Playback | 1/4/8/9 | |
| Alarms | N/A | |
| Dimension | Compact 1U 260x224.9x47.6mm | |
| Storage | 1 SATA (up to 6TB) | |
| Backup | USB Device/Network |
Eagle 4MP Dual Illumination IP Turret Cameras
The Eagle 4MP IP Turret Camera features image sensors, low luminance and HD imagery.
Features:
-Outputs max. 4 MP (2688 x 1520)@20 fps, and supports 2560 x 1440 @25/30 fps.
-H.265 Codec, high compression rate, ultra-low bit rate.
-Built-in warm light/IR LED, the max. illumination distance is 30m and the max. warm light distance is 30m.
-ROI, SMART H.264 /H.265 , flexible coding, applicable to various bandwidth and storage environments.
-Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
-Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).
-Supports max. 256 G Micro SD card; built in MIC
-12 VDC/PoE power supply, easy for installation.
-IP67 protection.
-SMD Plus.
